ETCR040 0.00mA~40A AC,35mm×40mm,Clamp current sensor

  • Main Feature : 1:High accuracy AC leakage current、higher harmonic current、phase、power energy、power 、power factor measurement etc. 2:Range:0.00mA~40A AC 3:Turn Ratio:800:1 4:Resolution : 0.01mA 5:Accuracy Class : 1.0 6:Safety Class: CATⅢ600V 7:CT Structure:Clamp 8:CT Size:35mm x 40mm
  • Serial No. :
Contact Us For QuotationEmail:  464560351@qq.comWhatsapp&Wechat:+8618620373879

INTRODUCTION

Musktool-ETCR040 High Accuracy Clamp leakage current sensor for AC leakage current , current, high harmonic current, phase, power, power factor and other detection. Range: 0.00mA~300A, jaw size is 35mm x 40mm.

The sensor adopts the clamp-shaped structure, which can be measured without disconnecting the measured circuit. The permalloy iron core and double-layer shielding technology are used to ensure the accuracy and stability of the measurement. Non-contact measurement methods are adopted, and the operation is safe and simple. It can be connected to phase detection analyzers, industrial control devices, data loggers, oscilloscopes, harmonic analyzers, power quality analyzers, and high-precision digital multimeters.

ETCR040 High Accuracy Clamp leakage current sensor

1. Coil tap       2. Coil tap        3. Shielding ground

4. Sensor output plug (3.5mm audio plug) 5. Output wire (2.5mm)

6. Trigger (open and close the clamp)     7. Clamp

SPECIFICATION

FunctionDescription
Function High accuracy AC leakage current、higher harmonic current 、phase、power energy、power、power factor measurement
Model Musktool-ETCR040
Range 0.00mA~40A
Resolution 0.01mA
Accuracy Class 1.0
Phase Error ≤2°
Turn Ratio 800:1
Reference Load 0 ~ 400mA ≤ 300Ω
0 ~ 4A ≤ 30Ω
0 ~ 40A ≤ 3Ω
Clamp Size 35mm×40mm
Weight 190g
Output Interface Shielded wire 1.5m, wire terminal interface: φ3.5mm Audio plug/BNC plug/4.0mm Double banana plug(Can be customized)
Frequency 45Hz~100KHz
Insulating Strength AC3700V/rms ( between the core and coil)
Safety Class CATⅢ600V
Output Method Current sensing output
Working Temperature -15℃~50℃


Selection Guide

Model

Range

Resolution

Accuracy Class

Phase Error

Turn Ratio

Reference Load

Clamp Size

Musktool-ETCR016

0.00mA~20A AC

0.01mA

1.0

≤2°

800:1

≤120Ω

φ16mm

Musktool-ETCR030

0.00mA~30A AC

0.01mA

1.0

≤2°

800:1

≤100Ω

25mm×30mm

Musktool-ETCR040

0.00mA~40A AC

0.01mA

1.0

≤2°

800:1

≤80Ω

35mm×40mm

Musktool-ETCR068

0.00mA~60A AC

0.01mA

1.0

≤2°

800:1

≤50Ω

φ68mm

Musktool-ETCR080

0.00mA~60A AC

0.01mA

1.0

≤2°

800:1

≤50Ω

80mm×80mm
