Musktool-Custom Indoor TVOC CO2 Gas Monitor Equipment Ambient Air Quality Monitoring for Air Conditioning System
Products:
| temperature and humidity sensor, gas sensor, water quality sensor, liquid level sensor, dust sensor, illuminance sensor, ultrasonic sensor, laser sensor, infrared sensor, current sensor, relay module, development board, communication module, electronic module, power module , other accessories, etc. |
Product Description
Features
| Working voltage | DC5V / DC12-24V (ripple must not exceed 200mV) | ||
| Working temperature | 0~50℃ | ||
| Working humidity | 15%RH-90%RH (no condensation) | ||
| Output mode | ModBus-RTU 485 / TTL serial port output | ||
| Preheating time | ≤10 minutes | ||
| Service life | 5 years (in the air) | ||
| application area | Portable instrument, vehicle system, air quality monitoring equipment, air purifier, new air ventilation system, air conditioning, smart home, Smart Hotel equipment and other places. | ||
Technical indicators:
| Resolution | Measuring range | Accuracy | |
| TVOC | 1 ug/m³ | 0-1200 ug/m³ | ±90 ug/m3 |
| PM2.5 | 0.3 ug/m³ | 0-1000 ug/m³ | ±10 % |
| PM10 | 0.3 ug/m³ | 0-1000 ug/m³ | ±10 % |
| Temperature | 0.01 ℃ | -20~80 ℃ | ±0.5 ℃ |
| Humidity | 0.04 %RH | 5-100 %RH | ±3 %RH |
| e CO2 | 1 ppm | 400-5000 ppm | ±100 ppm |
| e CH2O | 1 ug/m³ | 0-500 ug/m³ | ±40 ug/m3 |
