Brief Introduction and Aplications
1. Large flow sampling (28.3L/min), efficient and fast 2. Simultaneous testing of 6 particle sizes (0.3, 0.5, 1.0, 3.0, 5.0, 10.0μm) 3. External sensors can test ambient temperature, relative temperature, wind speed and differential pressure 4. 6.4inch true color touch screen 5. Can store 10,000 sets of data 6. Built-in printer, output test report directly 7. Directly judge whether the clean room level meets the requirements 8. External U disk can be connected to increase storage space 9. Conforms to JJF1190-2008 standard, counting report complies with GB/T16292-2010 and ISO14644-1 standard |
Technical parameters
Musktool-Kanomax 3905 28.3L Large Flow Dust Particle Counter
| Name | Kanomax Dust Particle Counter | ||
| model | 3905 | 3910 | 3920 |
| Traffic | 28.3L/min | 50L/min | 100L/min |
| Test particle size | Standard: 0.3, 0.5, 1.0, 3.0, 5.0, 10.0μm Non-standard: 6 kinds of particle sizes can be selected within 0.3~ 10.0μm | Standard: 0.5, 0.7, 1.0, 3.0, 5.0, 10.0μm Non-standard: 6 kinds of particle sizes can be selected within 0.5~ 10.0μm | |
| Counting efficiency | 50±20%@0.3μm Compliant with ISO21501-4 | 50±20%@0.5μm Compliant with ISO21501-4 | |
| Maximum Particle Concentration | 500,000pcs/cf | 300,000pcs/cf | |
| Particle size resolution | <15%@0.3μm Complies with ISO21501-4 | <15%@0.5μm Complies with ISO21501-4 | |
| standard test | ISO14644-1, New GMP, GB/T16292-2010, FEDERAL STANDARD, BRITISH STANDARD, EC GMP | ||
| language | Chinese-English | ||
| light source | laser diode | ||
| consistency loss | <150000pcs cf="">150000pcs/cf 10% Compliant with ISO21501-4 | ||
| Miscount | Below 0.2 pcs/cf conforms to ISO21501-4 | ||
| zero count | Conforms to JIS standard | ||
| show | 6.4inch true color touch screen | ||
| test method | Single, Interval, Continuous Standard, Statistics | ||
| Data Security | Compliant with 21 CFR Part11 | ||
| data storage | 10,000 sets of data (number of files), can also be copied from an external U disk | ||
| map coding | On-site drawings 0~999 | ||
| error display | Concentration overflow, light source abnormality, flow abnormality, limit value out of tolerance | ||
| Audio output | Built-in speaker, and two audio outputs for alarm and error | ||
| interface | USB、Ethernet | ||
| built-in printer | |||
| sampling time | 6sec～23h 59min 59sec | ||
| Sampling times | Repeat the test 1~9,999 times | ||
| count alarm | Within the range of 1 to 9,999,999 counts | ||
| external sensor | Wind speed, temperature and humidity, pressure | ||
| Battery | Rechargeable lithium battery (two battery slots) | ||
| power supply | 100～240V AC 50～60Hz | ||
| Warranty | Two years for the whole machine, three years for the laser light source | ||
| weight | About 4.5Kg (without battery) | About 5.0Kg (without battery) | |
| Dimensions | 200×205×200mm | 200×205×250mm | |
| Standard accessories | Operation manual, test report, zero count filter, lithium battery x 1, isodynamic sampling head, dust-free tube x 2m, AC adapter, communication software, printing paper | ||
| Optional | Environmental sensors (wind speed, temperature and humidity, differential pressure), high-voltage diffuser, scanning probe, carrying case | ||
