Musktool-Kanomax 3720-06 Remote Dust Particle Counter
Musktool-Kanomax 3720-06 Remote Dust Particle Counter
Musktool-Kanomax 3720-06 Remote Dust Particle Counter
Musktool-Kanomax 3720-06 Remote Dust Particle Counter

Musktool-Kanomax 3720-06 Remote Dust Particle Counter

2023-07-07 08:30:06

Remote Dust Particle Counter

  • Main Feature :
  • Serial No. :
Contact Us for QuotationEmail:464560351@qq.comWhatsapp: +8618620373879

图片关键词

Product introduction

  • 图片关键词With standard Modbus protocol and 4~20mA analog output function

  • 图片关键词 Simultaneous testing of four particle sizes (0.3, 0.5, 0.7, 1.0, 3.0, 5.0, 10.0 μm optional 2 ~ 4 particle sizes)

  • 图片关键词 Using long-life laser light source, mean trouble-free running time ≥ 10 years, 3-year warranty

  • 图片关键词 Can store 5,000 sets of data, and has 2,000 sets of test data cache, data redundancy backup function

  • 图片关键词 316 stainless steel shell and protective box are used and sealed, with super strong resistance to VHP and alcohol vapor

  • 图片关键词 Vacuum sampling pump can be disassembled independently, easy to install

  • 图片关键词 Adopt POE power supply, support hot swap, convenient maintenance and cost saving

Product Specifications

Musktool-Kanomax 3720-06 Remote Dust Particle Counter

model3720-06
Particle size0.5, 5.0μm (0.3, 0.5, 0.7, 1.0, 3.0, 5.0, 10.0μm optional 2 ~ particle size set before leaving the factory)
Traffic28.3L/min(1.0CFM)
light sourceLong-Life Laser Diodes
Counting efficiencyConforms to ISO21501-4, JIS B9921
Maximum measurable concentration1,000,000CNT/ft3
parameter settingsoutput range(Each particle size is set separately)
Quantity: 0~10CNT, 0~100CNT, 0~1,000CNT, 0~10,000CNT
Concentration: 0~10CNT/cf, 0~100CNT/cf, 0~1,000CNT/cf, 0~ 1000,000CNT/cf
0~353CNT/m 3 , 0~3,530CNT/m 3 , 0~35,300CNT/m 3 , 0~35,300,000CNT/m 3
Call the police0%~100%
Alarm OutputON/OFF
address0~512
Communication InterfaceEthernet, RS485, analog output 4~20mA
ProtocolModbus(RTU)、Modbus(TCP/IP)
Working air sourceBuilt-in vacuum air source (continuous operation over 20,000HR)
data storage5,000 groups (2,000 groups are cached)
operating languageChinese
surroundingsoperate10~30℃ 20~85%RH (no condensation)
save-10~50℃ below 95%RH (no condensation)
power supplyDC 15~28V, POE power supply, AC 100~240V
Dimensions180x110x190mm
weight4.0kg
Standard accessoriesAC adapter, instruction manual, isokinetic suction port, zero count filter
