GT280FNF Coating Thickness Gauge

Main Feature :
Serial No. : Zoe732

Specification

Contact Us For Quotation

Email: 464560351@qq.com

Whatsapp&Wechat:+8618620373879

GT280FNF Coating Thickness Gauge

Features

1.Menu-style operation with a color screen and high-definition display.

2.Measurement of non-magnetic coating thickness on magnetic metal substrates and non-metal coating thickness on non-magnetic metal substrates.

3.Offers both single and continuous measurement modes.

4.Provides basic and zero-point calibration functions.

5.Unit selection in µm or mil and automatic storage function.

6.Automatic shutdown option.

Specification

Measurement range	0~1800μm/70.8mil
Resolution	<100μm: 0.1μm;≥100μm: 1μm;0.1mil
Measurement error	≤150μm: ±5μm;>150μm: ±(3%H+1μm)
Minimum diameter of magnetic metal substrate	12mm
Minimum thickness of magnetic metal substrate	0.5mm
Minimum radius of curvature of magnetic convex substrate	2mm
Minimum radius of curvature of magnetic concave substrate	11mm
Minimum diameter of non-magnetic metal substrate	50mm
Minimum thickness of non-magnetic metal substrate	0.5mm
Operating voltage	DC 3.7V (Lithium battery capacity 1000mAh)
Product dimensions	1506535mm
