Musktool-RSFR-(2X) 125H Zero Halogen ,Flexible Heat Shrink Tubing

2023-07-07 08:42:58

Zero Halogen ,Flexible Heat Shrink Tubing

Email：464560351@qq.com

Whatsapp: +8618620373879

Product Features

Features : Flexible ,Zero halogen, Flame retardant, low smoke
Working Temperature:-55C ~105C
Shrink Temperature: 120C

Product Dismensions

物料缟号 Part Number	大小Size		供应内径 As supplied Internal oiameter	最大内径 lnternal Diameter Max mm	标称壁厚 Wall Thickness Nom mm	标准包装 Standard package
物料缟号 Part Number	英寸 lnch	mm	供应内径 As supplied Internal oiameter	最大内径 lnternal Diameter Max mm	标称壁厚 Wall Thickness Nom mm	线轴长度线轴 SpoollengthmSpool
2603 3001	3/64	0.8	11±0.2	0.50	0.22	200
2603 3002	1/16	1.0	1.5±0.2	0.65	0.28	200
2603 3002	1/16	1.5	2.0±0.2	0.85	0.32	200
2603 3003	3/32	2	2.5±0.2	1.00	0.35	200
2603 3003	3/32	2.5	3.0±0.2	1.30	0.38	200
2603 3004	18	3.0	3.5±0.2	1.50	0.40	200
		3.5	4.0±0.2	1.80	0.42	200
		4.0	4.5±0.2	2.00	0.45	200
2603 3005	3/16	4.5	5.0±0.2	2.30	0.50	200
2603 3005	3/16	5.0	5.5±0.2	2.5	0.55	10o
2603 3006	14	6.0	6.5+0.2	3.0	0.55	100
2603 3007	5/16	7.0	7.5±0.3	3.5	0.55	100
2603 3007	5/16	8.0	8.5±0.3	4.0	0.60	100
2603 3008	3/8	9.0	9.5±0.3	4.5	0.60	100
		10.0	10.5土0.3	5	0.60	100
		11.0	11.5±0.3	5.5	0.60	100
2603 3009	112	12.0	12.5±0.3	6.0	0.60	100
		13.0	13.5±0.3	6.5	0.65	100
		14.0	14.5±0.3	7.0	0.65	100
26033010	5/8	15.0	15.5±0.4	7.5	0.70	100
		16.0	16.5±0.4	8.0	0.70	100
		17.0	17.5±0.4	8.5	0.70	100
2603 3011	3/4	18.0	19.0±0.5	9.0	0.80	100
		20.0	21.0±0.5	10.0	0.80	100
		22.0	23.0±0.5	11.0	0.80	100

物料编号 Part Number	大小Size		供应内径 As supplied lnternal Diameter	最大内径 Internal Diameter Max mm	标称嬖厚 Wall Thickness Nom mm	标准包装 Standard package
物料编号 Part Number	英寸 lnch	mm	供应内径 As supplied lnternal Diameter	最大内径 Internal Diameter Max mm	标称嬖厚 Wall Thickness Nom mm	线轴长度/线轴 Spoollengthm/Spool
2603 3012		25	26.0土0.5	12.5	o.90	50
2603 3012		28	29.0±0.5	14.0	0.90	50
2603 3013	1-1/4	30	31.5±1.0	15.0	0.95	50
2603 3013	1-1/4	35	36.5±1.0	17.5	1.00	50
	1-1/2	40	41.5±1.0	20.0	1.00	50
	1-1/2	45	46.5±1.0	22.5	1.00	25
2603 3015	2	50	≥50	25.0	1.00	25
		60	≥60	31.0	1.30	25
		70	≥70	36.0	1.30	25
2603 3016	3	80	≥80	41.0	1.46	25
2603 3016	3	9o.0	≥90	46.0	1.46	25
2603 3017	4	100	≥100	51.0	1.46	25
2603 3018	5	120	≥120	61.0	1.56	25
2603 3019	6	150	≥150	76.0	1.56	25
2603 3020	7	180	≥180	91.0	1.56	25

Lable: Zero Halogen ,Flexible Heat Shrink Tubing
